C4.4 (Electronic Control System)

Units of measurement :

Metric

Imperial

Power Range

58.0R - 118 ekW

Frequency

50 / 60

Emissions

U.S. EPA Tier 3, EU Stage V

Availability

Purchase Rental Used

C4.4 (Electronic Control System)

Easy to use

• Simplicity = Reliability
• Configure the engine how you want it
• Compact engine profile with high power density
• Ease of repower with multiple cooling system options: Single circuit keel cooling /Separate circuit keel cooling / Heat exchanger
• Clean, smooth, and quiet operations
• Advanced fuel system provides excellent fuel consumption and low smoke
• Proven core engine design with millions of operating hours
• Fewer maintenance touchpoints and longer service intervals
• Global dealer network for unparalleled support

C4.4 GenSet (Electronic Control System) - Spec Sheet.pdf C4.4 GenSet (Electronic Control System) - Infographic.pdf C4.4 Marine Generator Set (Electronic Control System) Spec Sheet (58.0R - 118 ekW).pdf

Power Rating

Power Range

58.0R - 118 ekW

Generator Set Specifications

Engine Specifications

Dimensions & Weights

You might also be interested in:

C4.4 (Electronic Control System)

Emissions	U.S. EPA Tier 3, EU Stage V
Rated Engine Speed	1500/1800 rpm
Bore	105 mm	4.13 in
Stroke	127 mm	5 in
Displacement	4.4 l	269 in³
Aspiration	Turbocharged - Aftercooled and turbo only aspiration (Turbocharged aspiration only for 65ekW (71bkW))
Governor	Electronic (A5 ECM)
Refill Capacity	Lube Oil System w/Oil filter change: 11 L 2.8 gal)
Oil Change Interval	500 hours
Cooling	Heat exchanger, combined circuit keel cooling, or separate circuit keel cooling
Flywheel Housing	SAE No. 03 with SAE 11.5 flywheel (126 teeth)
Configuration	In-line 4, 4-stroke-cycle diesel

Maximum Length	2037 mm	80.2 in
Maximum Height	1999 mm	78.7 in
Maximum Width	986 mm	38.3 in
Maximum Engine Dry Weight	1537 kg	3389 lb
